48V 105AH LiFePO4 Golf Cart Battery Kit With Free Delivery
What Is Included In This Kit
(1) 48V 105AH Lithium Power LP51105 golf cart lithium battery.
(1) CAN Battery display with voltage, Battery %, Discharge current, Charge current and with 3M cable.
(1) Mounting hardware.
(1) Onboard RCM certified 25A Lifepo4 fast charger.
Battery mounting bracket.
Battery Specifications
Nominal voltage: 51V
Nominal capacity: 105AH
Cell chemistry: LifepO4
Stored energy: 5.3kWh
Maximum charge voltage: 57.6V
Minimum discharge voltage: 40V
Maximum charge current: 100A
Maximum continuous discharge current: 200A
Maximum burst current 30 seconds: 375A
Acceptable operating temperature: 0C – 60C
Battery case: Mild steel, welded and powder coated
Ip rating: IP65
Weight: 46KG
Dimensions: L 500mm W 335mm H 235mm
BMS – Charger CAN communication: Optional extra if required
BMS – Victron CAN communication available on request
Expected Range
There are many factors that can effect the range including cart weight, course gradient and others.
For a standard 2 seat cart + our LP51105 battery you can expect approximately 65KM of range.
It is not recommended to fully discharge your battery and whenever possible plug in and leave the charger connected when not in use.
Can The LP51105 Be Used For Other Applications?
Yes the LP51105 can be used for a wide range of applications including small mobile vehicles, fixed solar storage, caravan / motorhome storage and others.
On request we can configure our BMS to communicate with Victron CAN equipment supplying a suitable communication cable.
For Caravan installations we can install an external ventilation port to meet the new battery storage regulations.
Warranty Information
Your battery purchase will be covered under a 5 year warranty.
All batteries are put through a very thorough test procedure before they leave our workshop.
In the unlikely event there is a problem with you battery we will repair or completely replace your battery covering all freight costs involved.
Installers and Resellers
If you are an installer or reseller and want to supply / Install our golf cart batteries please send us a message with your business details and we will get in touch.
